помогите запустить TFT дисплей 2.4дюйма

http://ru.aliexpress.com/item/ForAr...For-UNO-R3/1949318944.html?detailNewVersion=2 купил такой дисплей пробую запускать видно как пиксели немного темнеют при старте ардуины затем все пропадает изображения нет может кто помочь с запуском ?



Смогут, если будет больше информации.
1. Какой контроллер в дисплее
2. Какой библиотекой пользуешься
3. Выложи тестовый скетч
4. На каком МК запускаешь дисплей



http://forum.banggood.com/forum-topic-93683.html
Вот здесь библиотека с семплами лежит для вашего экранчика на чипе ILI9335.



дисплей на чипе ILI9341
ардуно уно совместимый (китайский на отмега 328п
#include "SPI.h"
#include "Adafruit_GFX.h"
#include "Adafruit_ILI9340.h"

#if defined(__SAM3X8E__)
#undef __FlashStringHelper::F(string_literal)
#define F(string_literal) string_literal
#endif

// These are the pins used for the UNO
// for Due/Mega/Leonardo use the hardware SPI pins (which are different)
#define _sclk 13
#define _miso 12
#define _mosi 11
#define _cs 10
#define _dc 9
#define _rst 8

// Using software SPI is really not suggested, its incredibly slow
//Adafruit_ILI9340 tft = Adafruit_ILI9340(_cs, _dc, _mosi, _sclk, _rst, _miso);
// Use hardware SPI
Adafruit_ILI9340 tft = Adafruit_ILI9340(_cs, _dc, _rst);

void setup() {
Serial.begin(9600);
Serial.println("Adafruit 2.2\" SPI TFT Test!");
tft.begin();

Serial.println(F("Benchmark Time (microseconds)"));
Serial.print(F("Screen fill "));
Serial.println(testFillScreen());
delay(500);

Serial.print(F("Text "));
Serial.println(testText());
delay(3000);

Serial.print(F("Lines "));
Serial.println(testLines(ILI9340_CYAN));
delay(500);

Serial.print(F("Horiz/Vert Lines "));
Serial.println(testFastLines(ILI9340_RED, ILI9340_BLUE));
delay(500);

Serial.print(F("Rectangles (outline) "));
Serial.println(testRects(ILI9340_GREEN));
delay(500);

Serial.print(F("Rectangles (filled) "));
Serial.println(testFilledRects(ILI9340_YELLOW, ILI9340_MAGENTA));
delay(500);

Serial.print(F("Circles (filled) "));
Serial.println(testFilledCircles(10, ILI9340_MAGENTA));

Serial.print(F("Circles (outline) "));
Serial.println(testCircles(10, ILI9340_WHITE));
delay(500);

Serial.print(F("Triangles (outline) "));
Serial.println(testTriangles());
delay(500);

Serial.print(F("Triangles (filled) "));
Serial.println(testFilledTriangles());
delay(500);

Serial.print(F("Rounded rects (outline) "));
Serial.println(testRoundRects());
delay(500);

Serial.print(F("Rounded rects (filled) "));
Serial.println(testFilledRoundRects());
delay(500);

Serial.println(F("Done!"));
}

void loop(void) {
for(uint8_t rotation=0; rotation<4; rotation++) {
tft.setRotation(rotation);
testText();
delay(2000);
}
}


unsigned long testFillScreen() {
unsigned long start = micros();
tft.fillScreen(ILI9340_BLACK);
tft.fillScreen(ILI9340_RED);
tft.fillScreen(ILI9340_GREEN);
tft.fillScreen(ILI9340_BLUE);
tft.fillScreen(ILI9340_BLACK);
return micros() - start;
}

unsigned long testText() {
tft.fillScreen(ILI9340_BLACK);
unsigned long start = micros();
tft.setCursor(0, 0);
tft.setTextColor(ILI9340_WHITE); tft.setTextSize(1);
tft.println("Hello World!");
tft.setTextColor(ILI9340_YELLOW); tft.setTextSize(2);
tft.println(1234.56);
tft.setTextColor(ILI9340_RED); tft.setTextSize(3);
tft.println(0xDEADBEEF, HEX);
tft.println();
tft.setTextColor(ILI9340_GREEN);
tft.setTextSize(5);
tft.println("Groop");
tft.setTextSize(2);
tft.println("I implore thee,");
tft.setTextSize(1);
tft.println("my foonting turlingdromes.");
tft.println("And hooptiously drangle me");
tft.println("with crinkly bindlewurdles,");
tft.println("Or I will rend thee");
tft.println("in the gobberwarts");
tft.println("with my blurglecruncheon,");
tft.println("see if I don't!");
return micros() - start;
}

unsigned long testLines(uint16_t color) {
unsigned long start, t;
int x1, y1, x2, y2,
w = tft.width(),
h = tft.height();

tft.fillScreen(ILI9340_BLACK);

x1 = y1 = 0;
y2 = h - 1;
start = micros();
for(x2=0; x2<w; x2+=6) tft.drawLine(x1, y1, x2, y2, color);
x2 = w - 1;
for(y2=0; y2<h; y2+=6) tft.drawLine(x1, y1, x2, y2, color);
t = micros() - start; // fillScreen doesn't count against timing

tft.fillScreen(ILI9340_BLACK);

x1 = w - 1;
y1 = 0;
y2 = h - 1;
start = micros();
for(x2=0; x2<w; x2+=6) tft.drawLine(x1, y1, x2, y2, color);
x2 = 0;
for(y2=0; y2<h; y2+=6) tft.drawLine(x1, y1, x2, y2, color);
t += micros() - start;

tft.fillScreen(ILI9340_BLACK);

x1 = 0;
y1 = h - 1;
y2 = 0;
start = micros();
for(x2=0; x2<w; x2+=6) tft.drawLine(x1, y1, x2, y2, color);
x2 = w - 1;
for(y2=0; y2<h; y2+=6) tft.drawLine(x1, y1, x2, y2, color);
t += micros() - start;

tft.fillScreen(ILI9340_BLACK);

x1 = w - 1;
y1 = h - 1;
y2 = 0;
start = micros();
for(x2=0; x2<w; x2+=6) tft.drawLine(x1, y1, x2, y2, color);
x2 = 0;
for(y2=0; y2<h; y2+=6) tft.drawLine(x1, y1, x2, y2, color);

return micros() - start;
}

unsigned long testFastLines(uint16_t color1, uint16_t color2) {
unsigned long start;
int x, y, w = tft.width(), h = tft.height();

tft.fillScreen(ILI9340_BLACK);
start = micros();
for(y=0; y<h; y+=5) tft.drawFastHLine(0, y, w, color1);
for(x=0; x<w; x+=5) tft.drawFastVLine(x, 0, h, color2);

return micros() - start;
}

unsigned long testRects(uint16_t color) {
unsigned long start;
int n, i, i2,
cx = tft.width() / 2,
cy = tft.height() / 2;

tft.fillScreen(ILI9340_BLACK);
n = min(tft.width(), tft.height());
start = micros();
for(i=2; i<n; i+=6) {
i2 = i / 2;
tft.drawRect(cx-i2, cy-i2, i, i, color);
}

return micros() - start;
}

unsigned long testFilledRects(uint16_t color1, uint16_t color2) {
unsigned long start, t = 0;
int n, i, i2,
cx = tft.width() / 2 - 1,
cy = tft.height() / 2 - 1;

tft.fillScreen(ILI9340_BLACK);
n = min(tft.width(), tft.height());
for(i=n; i>0; i-=6) {
i2 = i / 2;
start = micros();
tft.fillRect(cx-i2, cy-i2, i, i, color1);
t += micros() - start;
// Outlines are not included in timing results
tft.drawRect(cx-i2, cy-i2, i, i, color2);
}

return t;
}

unsigned long testFilledCircles(uint8_t radius, uint16_t color) {
unsigned long start;
int x, y, w = tft.width(), h = tft.height(), r2 = radius * 2;

tft.fillScreen(ILI9340_BLACK);
start = micros();
for(x=radius; x<w; x+=r2) {
for(y=radius; y<h; y+=r2) {
tft.fillCircle(x, y, radius, color);
}
}

return micros() - start;
}

unsigned long testCircles(uint8_t radius, uint16_t color) {
unsigned long start;
int x, y, r2 = radius * 2,
w = tft.width() + radius,
h = tft.height() + radius;

// Screen is not cleared for this one -- this is
// intentional and does not affect the reported time.
start = micros();
for(x=0; x<w; x+=r2) {
for(y=0; y<h; y+=r2) {
tft.drawCircle(x, y, radius, color);
}
}

return micros() - start;
}

unsigned long testTriangles() {
unsigned long start;
int n, i, cx = tft.width() / 2 - 1,
cy = tft.height() / 2 - 1;

tft.fillScreen(ILI9340_BLACK);
n = min(cx, cy);
start = micros();
for(i=0; i<n; i+=5) {
tft.drawTriangle(
cx , cy - i, // peak
cx - i, cy + i, // bottom left
cx + i, cy + i, // bottom right
tft.Color565(0, 0, i));
}

return micros() - start;
}

unsigned long testFilledTriangles() {
unsigned long start, t = 0;
int i, cx = tft.width() / 2 - 1,
cy = tft.height() / 2 - 1;

tft.fillScreen(ILI9340_BLACK);
start = micros();
for(i=min(cx,cy); i>10; i-=5) {
start = micros();
tft.fillTriangle(cx, cy - i, cx - i, cy + i, cx + i, cy + i,
tft.Color565(0, i, i));
t += micros() - start;
tft.drawTriangle(cx, cy - i, cx - i, cy + i, cx + i, cy + i,
tft.Color565(i, i, 0));
}

return t;
}

unsigned long testRoundRects() {
unsigned long start;
int w, i, i2,
cx = tft.width() / 2 - 1,
cy = tft.height() / 2 - 1;

tft.fillScreen(ILI9340_BLACK);
w = min(tft.width(), tft.height());
start = micros();
for(i=0; i<w; i+=6) {
i2 = i / 2;
tft.drawRoundRect(cx-i2, cy-i2, i, i, i/8, tft.Color565(i, 0, 0));
}

return micros() - start;
}

unsigned long testFilledRoundRects() {
unsigned long start;
int i, i2,
cx = tft.width() / 2 - 1,
cy = tft.height() / 2 - 1;

tft.fillScreen(ILI9340_BLACK);
start = micros();
for(i=min(tft.width(), tft.height()); i>20; i-=6) {
i2 = i / 2;
tft.fillRoundRect(cx-i2, cy-i2, i, i, i/8, tft.Color565(0, i, 0));
}

return micros() - start;
}



у производителя нашел это просто серым светится и все



Вы в fritzing нарисуйте схему. И скетч в специальное место. 95% даю, что у Вас просто где-то неконтакт!



она ставится в раземе мк без переходников
