Дело в том что сканер читает брелок, но не читает вот эту белую карточку. Вот что приходит с брелка: Код (Text): Card UID: F9 01 9E 1A PICC type: MIFARE 1KB Sector Block 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 AccessBits 15 63 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 62 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 61 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 60 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 14 59 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 58 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 57 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 56 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 13 55 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 54 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 53 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 52 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 12 51 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 50 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 49 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 48 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 11 47 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 46 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 45 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 44 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 10 43 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 42 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 41 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 40 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 9 39 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 38 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 37 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 36 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 8 35 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 34 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 33 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 32 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 7 31 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 30 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 29 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 28 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 6 27 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 26 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 25 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 24 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 5 23 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 22 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 21 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 4 19 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 18 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 17 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 16 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 3 15 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 14 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 13 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 12 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 2 11 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 10 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 9 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 8 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 1 7 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 6 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 5 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 4 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 0 3 00 00 00 00 00 00 FF 07 80 69 FF FF FF FF FF FF [ 0 0 1 ] 2 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 1 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [ 0 0 0 ] 0 F9 01 9E 1A 7C 08 04 00 62 63 64 65 66 67 68 69 [ 0 0 0 ] Библиотеку брал отсюда: http://www.youtube.com/redirect?q=h...GEbretshyvGB-fmF8MTQyMTAwMzY5MUAxNDIwOTE3Mjkx Вот скетч: Код (Text): /* * ---------------------------------------------------------------------------- * This is a MFRC522 library example; see https://github.com/miguelbalboa/rfid * for further details and other examples. * * NOTE: The library file MFRC522.h has a lot of useful info. Please read it. * * Released into the public domain. * ---------------------------------------------------------------------------- * Example sketch/program showing how to read data from a PICC (that is: a RFID * Tag or Card) using a MFRC522 based RFID Reader on the Arduino SPI interface. * * When the Arduino and the MFRC522 module are connected (see the pin layout * below), load this sketch into Arduino IDE then verify/compile and upload it. * To see the output: use Tools, Serial Monitor of the IDE (hit Ctrl+Shft+M). * When you present a PICC (that is: a RFID Tag or Card) at reading distance * of the MFRC522 Reader/PCD, the serial output will show the ID/UID, type and * any data blocks it can read. Note: you may see "Timeout in communication" * messages when removing the PICC from reading distance too early. * * If your reader supports it, this sketch/program will read all the PICCs * presented (that is: multiple tag reading). So if you stack two or more * PICCs on top of each other and present them to the reader, it will first * output all details of the first and then the next PICC. Note that this * may take some time as all data blocks are dumped, so keep the PICCs at * reading distance until complete. * * Typical pin layout used: * ------------------------------------------------------------ * MFRC522 Arduino Arduino Arduino * Reader/PCD Uno Mega Nano v3 * Signal Pin Pin Pin Pin * ------------------------------------------------------------ * RST/Reset RST 9 5 D9 * SPI SS SDA(SS) 10 53 D10 * SPI MOSI MOSI 11 / ICSP-4 51 D11 * SPI MISO MISO 12 / ICSP-1 50 D12 * SPI SCK SCK 13 / ICSP-3 52 D13 */ #include <SPI.h> #include <MFRC522.h> #define RST_PIN 9 // #define SS_PIN 10 // MFRC522 mfrc522(SS_PIN, RST_PIN); // Create MFRC522 instance void setup() { Serial.begin(9600); // Initialize serial communications with the PC SPI.begin(); // Init SPI bus mfrc522.PCD_Init(); // Init MFRC522 ShowReaderDetails(); // Show details of PCD - MFRC522 Card Reader details Serial.println("Scan PICC to see UID, type, and data blocks..."); } void loop() { // Look for new cards if ( ! mfrc522.PICC_IsNewCardPresent()) { return; } // Select one of the cards if ( ! mfrc522.PICC_ReadCardSerial()) { return; } // Dump debug info about the card; PICC_HaltA() is automatically called mfrc522.PICC_DumpToSerial(&(mfrc522.uid)); } void ShowReaderDetails() { // Get the MFRC522 software version byte v = mfrc522.PCD_ReadRegister(mfrc522.VersionReg); Serial.print("MFRC522 Software Version: 0x"); Serial.print(v, HEX); if (v == 0x91) Serial.print(" = v1.0"); else if (v == 0x92) Serial.print(" = v2.0"); else Serial.print(" (unknown)"); Serial.println(""); // When 0x00 or 0xFF is returned, communication probably failed if ((v == 0x00) || (v == 0xFF)) { Serial.println("WARNING: Communication failure, is the MFRC522 properly connected?"); } } Вроде все подключил правильно. Помогите пожалуйста!
Таж ситуация, перепробовал кучу офисных Mifare пропусков - не читает.... При этом родной брелок работает
Да, такая же ситуация, не читает то карточки, то брелки. По видимому на модуле слабая антенна, или скорее всего в брелках. Все мои брелки и карточки читаются на другом считывателе. Подключаю RC522 к Ардуино, беру одну карточку, пробую считать - не считывает, беру вторую - тоже самое, тишина. Тогда я сложил их вместе друг к другу, подношу к ридеру и карточка считалась на расстоянии около 1см. Испытывал несколько раз, по отдельности не хотят, а вместе читаются. Тогда я решил попробовать с брелками которые не считывались, они стали считываться.
