Ardino+W5100->Mqtt->OpenHab

Securbond · 13 мар 2016

Дабы не флудить в чужих темах ..
Есть задача передавать (принимать) данные между UNO+W5100 и OpenHab
Пока что первая проблема это передать не статичные данные а переменную.

Код (C++):

#include <SPI.h>
#include <Ethernet.h>
#include <PubSubClient.h>
char t = 0;
// Update these with values suitable for your network.
byte mac[] = { 0xDE, 0xED, 0xBA, 0xFE, 0xFE, 0xED };
IPAddress ip(192, 168, 0, 15);
IPAddress server(192, 168, 0, 100);

void callback(char* topic, byte* payload, unsigned int length) {
Serial.print("Message arrived [");
Serial.print(topic);
Serial.print("] ");
for (int i=0;i<length;i++) {
Serial.print((char)payload[i]);
}
Serial.println();
}

EthernetClient ethClient;
PubSubClient client(ethClient);

void reconnect() {
// Loop until we're reconnected
while (!client.connected()) {
Serial.println("Attempting MQTT connection...");
// Attempt to connect
if (client.connect("arduinoClient")) {
Serial.println("connected");
}
else {
Serial.print("failed, rc=");
Serial.print(client.state());
Serial.println(" try again in 5 seconds");
delay(5000);
}
}
}
void setup()
{
Serial.begin(9600);

client.setServer(server, 1883);
client.setCallback(callback);

Ethernet.begin(mac, ip);
// Allow the hardware to sort itself out
delay(1500);
}

void loop()
{
if (!client.connected()) {
reconnect();
}
for ( t = 150; t >= 0; t--){
// Once connected, publish an announcement...
String toSend = (String) t;
client.publish("test",toSend);
}

}

Выскакивает следующая

Код (C++):

no matching function for call to 'PubSubClient::publish(const char [5], String&)'

Прошу помощи зала.

Securbond · 23 мар 2016

1. Нашел рабочий код с переменными!

Код (C++):

#include <SPI.h>
#include <Ethernet.h>
#include <PubSubClient.h>
char t = 0;
// Update these with values suitable for your network.
byte mac[] = { 0xDE, 0xED, 0xBA, 0xFE, 0xFE, 0xED };
IPAddress ip(192, 168, 0, 15);
IPAddress server(192, 168, 0, 100);
int sensorPin=5;
int lastTemperature;
unsigned long lastTime;
char buffer[10];

void callback(char* topic, byte* payload, unsigned int length) {
// handle message arrived (no messages expected though)
}

EthernetClient ethClient;
PubSubClient client(server, 1883, callback, ethClient);

void setup() {
Ethernet.begin(mac, ip);
if (client.connect("arduinoClient")) {
client.publish("test/status/arduino01","online");
lastTemperature=0;
lastTime=0;
}
}

void loop() {
int reading=analogRead(sensorPin);
int temperature = ((reading * 0.004882)-0.50)*100;
if(temperature!=lastTemperature) {
if(millis()>(lastTime+1000)) {
sprintf(buffer,"%d",temperature);
client.publish("test/device/arduino01",buffer);
lastTemperature=temperature;
lastTime=millis();
}
}
client.loop();
}

Добавил функцию переподключения при потере связи.

Код (C++):

#include <SPI.h>
#include <Ethernet.h>
#include <PubSubClient.h>
char t = 0;
// Update these with values suitable for your network.
byte mac[] = { 0xDE, 0xED, 0xBA, 0xFE, 0xFE, 0xED };
IPAddress ip(192, 168, 0, 15);
IPAddress server(192, 168, 0, 100);
int sensorPin=5;
int lastTemperature;
unsigned long lastTime;
char buffer[5];

void callback(char* topic, byte* payload, unsigned int length) {
// handle message arrived (no messages expected though)
}

EthernetClient ethClient;
PubSubClient client(server, 1883, callback, ethClient);

void reconnect() {
// Loop until we're reconnected
while (!client.connected()) {
Serial.println("Attempting MQTT connection...");
// Attempt to connect
if (client.connect("arduinoClient")) {
Serial.println("connected");
}
else {
Serial.print("failed, rc=");
Serial.print(client.state());
Serial.println(" try again in 5 seconds");
delay(5000);
}
}
}
void setup() {
Serial.begin(9600);
Ethernet.begin(mac, ip);
if (client.connect("arduinoClient")) {
Serial.print("online");
lastTemperature=0;
lastTime=0;
}
}

void loop() {
if (!client.connected()) {
reconnect();
}
int reading=analogRead(sensorPin);
int temperature = ((reading * 0.004882)-0.50)*100;
if(temperature!=lastTemperature) {
if(millis()>(lastTime+1000)) {
sprintf(buffer,"%d",temperature);
client.publish("test/device/arduino01",buffer);
lastTemperature=temperature;
lastTime=millis();
}
}
client.loop();
}

Securbond · 23 мар 2016

2. Подключены 2шт DS18b20

Код (C++):

#include <SPI.h>
#include <Ethernet.h>
#include <PubSubClient.h>
#include <OneWire.h>
#include <DallasTemperature.h>

#define ONE_WIRE_BUS 5
OneWire oneWire(ONE_WIRE_BUS);
DallasTemperature sensors(&oneWire);

DeviceAddress Thermometer1 = { 0x28, 0xFF, 0x62, 0x42, 0x62, 0x15, 0x01, 0x9A }; // адрес датчика DS18B20 280054B604000092
DeviceAddress Thermometer2 = { 0x28, 0xFF, 0xE7, 0x2C, 0xA6, 0x15, 0x01, 0xCB };
IPAddress ip(192, 168, 0, 15);
IPAddress server(XXX, XXX, XXX, XXX);
byte mac[] = { 0xDE, 0xED, 0xBA, 0xFE, 0xFE, 0xED };
char tmp1[10];
char tmp2[10];
unsigned long loopTime;
unsigned long currentTime;

EthernetClient ethClient;
PubSubClient client(server, 1883, callback, ethClient);

void callback(char* topic, byte* payload, unsigned int length) {
// handle message arrived (no messages expected though)
}

void reconnect() {
while (!client.connected()) {
Serial.println("Attempting MQTT connection...");
// Attempt to connect
if (client.connect("arduinoClient")) {
Serial.println("connected");
}
else {
Serial.print("failed, rc=");
Serial.print(client.state());
Serial.println(" try again in 5 seconds");
delay(3000);
}
}
}

void setup() {
Serial.begin(9600);
sensors.begin();
sensors.setResolution(Thermometer1, 10);
sensors.setResolution(Thermometer2, 10);
currentTime = millis();
loopTime = currentTime;
Ethernet.begin(mac, ip);
if (client.connect("arduinoClient")) {
Serial.println("online");
}
}
void loop() {
client.loop();
currentTime = millis();
sensors.requestTemperatures();
if(currentTime >= (loopTime + 10000)){
if (!client.connected()) {
reconnect();
}
float temperature1 = sensors.getTempC(Thermometer1);
float temperature2 = sensors.getTempC(Thermometer2);
dtostrf(temperature1, -2, 1, tmp1);
client.publish("test/device/arduino01/temp1",tmp1);
dtostrf(temperature2, -2, 1, tmp2);
client.publish("test/device/arduino01/temp2",tmp2);

loopTime = currentTime;
}
}

Итемы для OpenHab

Код (Java):

Number ds1 "t° Обратки [%.1f °C]" <temperature> { mqtt="<[mosquitto:test/device/arduino01/temp1:state:default]" }
Number ds2 "t° Подачи [%.1f °C]" <temperature> { mqtt="<[mosquitto:test/device/arduino01/temp2:state:default]" }

Далее в планах прикрутить управление внешними устройствами.

Securbond · 23 мар 2016

3. Добавлено 2 реле !!

Код (C++):

#include <SPI.h>
#include <Ethernet.h>
#include <PubSubClient.h>
#include <OneWire.h>
#include <DallasTemperature.h>
int REL1; // not sensing light, LED off
int REL2; // not sensing light, LED off
#define ONE_WIRE_BUS 5
#define rel1_pin 6
#define rel2_pin 7
OneWire oneWire(ONE_WIRE_BUS);
DallasTemperature sensors(&oneWire);

DeviceAddress Thermometer1 = { 0x28, 0xFF, 0x62, 0x42, 0x62, 0x15, 0x01, 0x9A }; // адрес датчика DS18B20 280054B604000092
DeviceAddress Thermometer2 = { 0x28, 0xFF, 0xE7, 0x2C, 0xA6, 0x15, 0x01, 0xCB };

IPAddress ip(192, 168, 0, 15);
IPAddress server(XXX, XXX, XXX, XXX);
byte mac[] = { 0xDE, 0xED, 0xBA, 0xFE, 0xFE, 0xED };
char tmp1[10];
char tmp2[10];
unsigned long loopTime;
unsigned long currentTime;
char message_buff[100];
EthernetClient ethClient;
PubSubClient client(server, 1883, callback, ethClient);

void callback(char* topic, byte* payload, unsigned int length) {
payload[length] = '\0';
Serial.print(topic);
Serial.print(" ");
String strTopic = String(topic);
String strPayload = String((char*)payload);
Serial.println(strPayload);
if (strTopic == "test/device/arduino01/rel1") {
if (strPayload == "ON"){REL1 = 1;}
else if (strPayload == "OFF"){REL1 = 0;}
Serial.print("REL1 = ");
Serial.println(REL1);
}
else if (strTopic == "test/device/arduino01/rel2") {
if (strPayload == "ON") {REL2 = 1;}
else if (strPayload == "OFF") {REL2 = 0;}
Serial.print("REL2 = ");
Serial.println(REL2);
}
}

void reconnect() {
while (!client.connected()) {
Serial.println("Attempting MQTT connection...");
// Attempt to connect
if (client.connect("arduinoClient")) {
Serial.println("connected");
}
else {
Serial.print("failed, rc=");
Serial.print(client.state());
Serial.println(" try again in 5 seconds");
delay(3000);
}
}
}

void setup() {
Serial.begin(9600);
pinMode(rel1_pin, OUTPUT);
digitalWrite(rel1_pin, LOW);
pinMode(rel2_pin, OUTPUT);
digitalWrite(rel2_pin, LOW);

sensors.begin();
sensors.setResolution(Thermometer1, 10);
sensors.setResolution(Thermometer2, 10);

currentTime = millis();
loopTime = currentTime;

Ethernet.begin(mac, ip);
if (client.connect("arduinoClient")) {
Serial.println("online");
client.publish("test/device/arduino01/rel1", "OFF");
client.publish("test/device/arduino01/rel2", "OFF");
client.subscribe("test/device/arduino01/#");
}
}
void loop() {
if (REL1 == 0) digitalWrite(rel1_pin, LOW);
else if (REL1 == 1) digitalWrite(rel1_pin, HIGH);
if (REL2 == 0) digitalWrite(rel2_pin, LOW);
else if (REL2 == 1) digitalWrite(rel2_pin, HIGH);

client.loop();
currentTime = millis();
sensors.requestTemperatures();
if(currentTime >= (loopTime + 10000)){

if (!client.connected()) {
reconnect();
}
float temperature1 = sensors.getTempC(Thermometer1);
float temperature2 = sensors.getTempC(Thermometer2);
dtostrf(temperature1, -2, 1, tmp1);
client.publish("test/device/arduino01/temp1",tmp1);
dtostrf(temperature2, -2, 1, tmp2);
client.publish("test/device/arduino01/temp2",tmp2);

loopTime = currentTime;
}
}

и итемы

Код (Java):

Switch Reley1 "Реле1" { mqtt=">[mosquitto:test/device/arduino01/rel1:command:on:ON],>[mosquitto:test/device/arduino01/rel1:command:off:OFF],<[mosquitto:test/device/arduino01/rel1:state:MAP(switchMQTT.map)]" }
Switch Reley2 "Реле2" { mqtt=">[mosquitto:test/device/arduino01/rel2:command:on:ON],>[mosquitto:test/device/arduino01/rel2:command:off:OFF],<[mosquitto:test/device/arduino01/rel2:state:MAP(switchMQTT.map)]" }

Securbond · 17 ноя 2016

4. Добавлена функция управления реле по заданной температуре.

Код (C++):

#include <SPI.h>
#include <Ethernet.h>
#include <PubSubClient.h>
#include <OneWire.h>
#include <DallasTemperature.h>
#define ONE_WIRE_BUS 5
#define rel1_pin 6
#define rel2_pin 7
char REL1; // not sensing light, LED off
char REL2; // not sensing light, LED off
char tmp1[10];
char tmp2[10];
char tUstav1;
char StrtUstav11[3];
unsigned long loopTime;
unsigned long currentTime;

OneWire oneWire(ONE_WIRE_BUS);
DallasTemperature sensors(&oneWire);
DeviceAddress Thermometer1 = { 0x28, 0xFF, 0x62, 0x42, 0x62, 0x15, 0x01, 0x9A };
DeviceAddress Thermometer2 = { 0x28, 0xFF, 0xE7, 0x2C, 0xA6, 0x15, 0x01, 0xCB };
IPAddress ip(192, 168, 0, 15);
IPAddress server(XXX, XXX, XXX, XXX);
byte mac[] = { 0xDE, 0xED, 0xBA, 0xFE, 0xFE, 0xED };
EthernetClient ethClient;
PubSubClient client(server, 1883, callback, ethClient);

void callback(char* topic, byte* payload, unsigned int length) {
payload[length] = '\0';
Serial.print(topic);
Serial.print(" ");
String strTopic = String(topic);
String strPayload = String((char*)payload);
Serial.println(strPayload);
if (strTopic == "test/device/arduino01/rel1") {
if (strPayload == "ON"){REL1 = 1;}
else if (strPayload == "OFF"){REL1 = 0;}
}
else if (strTopic == "test/device/arduino01/rel2") {
if (strPayload == "ON") {REL2 = 1;}
else if (strPayload == "OFF") {REL2 = 0;}
}
else if (strTopic == "test/device/arduino01/kotel1/get") {
char tUstav11;
tUstav11 = atoi((char*)payload);
if (tUstav11 != tUstav1 ) {
tUstav1 = tUstav11;
}
}
}
void reconnect() {
while (!client.connected()) {
Serial.println("Attempting MQTT connection...");
// Attempt to connect
if (client.connect("arduinoClient")) {
Serial.println("connected");
}
else {
Serial.print("failed, rc=");
Serial.print(client.state());
Serial.println(" try again in 5 seconds");
delay(3000);
}
}
}
void setup() {
Serial.begin(9600);
pinMode(rel1_pin, OUTPUT);
digitalWrite(rel1_pin, LOW);
pinMode(rel2_pin, OUTPUT);
digitalWrite(rel2_pin, LOW);
sensors.begin();
sensors.setResolution(Thermometer1, 10);
sensors.setResolution(Thermometer2, 10);
currentTime = millis();
loopTime = currentTime;
Ethernet.begin(mac, ip);
if (client.connect("arduinoClient")) {
Serial.println("online");
client.publish("test/device/arduino01/rel1", "OFF");
client.publish("test/device/arduino01/rel2", "OFF");
client.publish("test/device/arduino01/kotel1/get", "37");
client.subscribe("test/device/arduino01/#");
}
}
void loop() {
if (REL1 == 0) digitalWrite(rel1_pin, LOW);
else if (REL1 == 1) digitalWrite(rel1_pin, HIGH);
if (REL2 == 0) digitalWrite(rel2_pin, LOW);
else if (REL2 == 1) digitalWrite(rel2_pin, HIGH);
if ((sensors.getTempC(Thermometer2)) < tUstav1 && REL2==0) {
REL2 = 1;
client.publish("test/device/arduino01/rel2", "ON");
Serial.println("REL2 - ON");
}
else if ((sensors.getTempC(Thermometer2)) >= tUstav1 && REL2==1) {
REL2=0;
client.publish("test/device/arduino01/rel2", "OFF");
Serial.println("REL2 - OFF");
}

client.loop();
currentTime = millis();
sensors.requestTemperatures();
if(currentTime >= (loopTime + 15000)){
if (!client.connected()) {
reconnect();
}
float temperature1 = sensors.getTempC(Thermometer1);
float temperature2 = sensors.getTempC(Thermometer2);
dtostrf(temperature1, -2, 1, tmp1);
client.publish("test/device/arduino01/temp1",tmp1);
dtostrf(temperature2, -2, 1, tmp2);
client.publish("test/device/arduino01/temp2",tmp2);
dtostrf(tUstav1, -2, 0, StrtUstav11);
client.publish("test/device/arduino01/kotel1/get", StrtUstav11);
loopTime = currentTime;
}
}

Буду признателен если кто то даст совет по оптимизации кода. сейчас он занимает 70% памяти контроллера.

Items:

Код (Java):

Number ds1 "t° Обратки [%.1f °C]" <temperature> { mqtt="<[mosquitto:test/device/arduino01/temp1:state:default]" }
Number ds2 "t° Подачи [%.1f °C]" <temperature> { mqtt="<[mosquitto:test/device/arduino01/temp2:state:default]" }
Switch Reley1 "Реле1" { mqtt=">[mosquitto:test/device/arduino01/rel1:command:on:ON],>[mosquitto:test/device/arduino01/rel1:command:off:OFF],<[mosquitto:test/device/arduino01/rel1:state:default]" }
Switch Reley2 "Реле2" { mqtt=">[mosquitto:test/device/arduino01/rel2:command:on:ON],>[mosquitto:test/device/arduino01/rel2:command:off:OFF],<[mosquitto:test/device/arduino01/rel2:state:default]" }
Number Kotel_Show_Get "Уставка подачи [%.2f °C]" <temperature> { mqtt="<[mosquitto:test/device/arduino01/kotel1/get:state:default]" }
Number Kotel_Getting "Отопление Скрытая Цель [%.2f °C]" <temperature> { mqtt="<[mosquitto:test/device/arduino01/kotel1/get:state:default]" }
Number Kotel_Proxy "Отопление для команд [%.2f C]" <temperature> { mqtt=">[mosquitto:test/device/arduino01/kotel1/get:command:*:default]" }
String Relay2_Getting "Реле2 состояние" { mqtt="<[mosquitto:test/device/arduino01/rel2:state:default]" }

sitemap:

Код (Java):

Frame label="Arduino+W5100" {
Text item=ds2
Text item=ds1
Text item=Kotel_Show_Get
Setpoint item=Kotel_Getting label="Реулировка Уставки 37-80°C [%.1f °C]" icon="temperature" minValue=37 maxValue=80 step=1
}
Frame {
Switch item=Reley1
Switch item=Reley2
}

rules:

Код (Java):

import org.openhab.core.library.types.*
import org.openhab.core.persistence.*
import org.openhab.model.script.actions.*

var Timer timer11 = null

rule "change heating"

when

Item Kotel_Getting changed

then
if (timer11 != null)
timer11.cancel()
timer11 = createTimer(now.plusSeconds(5)) [|
{
sendCommand(Kotel_Proxy, Kotel_Getting.state.toString)
}
]
end

P/S: Отдельное спасибо выражаю ИгорюК! Без его примеров времени и сил было бы потрачено в разы больше. И другим участникам форума за умные мысли и полезные советы.

Securbond · 23 мар 2016

Не знаю писалось тут или нет, но на всякий случай, может кому то пригодится.
5. Ставим пароль на доступ к OpenHab
1. Редактируем файл users.cfg из директории /opt/openhab/configurations
в файле пишем:

user1=pass1

Думаю тут все понятно. Пользователей может быть несколько. Сохраняем файл.
2. В файле openhab.cfg из той же директории ищем
#######################################################################################
##### General configurations #####
#######################################################################################

удаляем одну # и пишем длинное слово ON , Должно получиться вот так:

Код (Java):

# configures the security options. The following values are valid:
# ON = security is switched on generally
# OFF = security is switched off generally
# EXTERNAL = security is switched on for external requests
# (e.g. originating from the Internet) only
# (optional, defaults to 'OFF')
security:option=ON

3. Перезагружаем сервис OpenHab.
4. Радуемся результату.

vasgen · 17 ноя 2016

делаю подобный небольшой проект управления отоплением на даче
1. Интернет там есть
2. железо Arduino Mega, w5100
3. Сенсоры и реле....

Прочитал ваш пост.
Ничего не понял про всякие Items:, mqtt=">[mosquitto: и прочее
На самой Arduine проекты пишу
Буду признателен.

Securbond · 17 ноя 2016

vasgen сказал(а): ↑

делаю подобный небольшой проект управления отоплением на даче
1. Интернет там есть
2. железо Arduino Mega, w5100
3. Сенсоры и реле....

Прочитал ваш пост.
Ничего не понял про всякие Items:, mqtt=">[mosquitto: и прочее
На самой Arduine проекты пишу
Буду признателен.
Нажмите, чтобы раскрыть...

Если не поняли, то почитайте ветку ИгоряК про OpenHab, возможно станет понятнее.

Ardino+W5100->Mqtt->OpenHab

Securbond Гуру

Securbond Гуру

Securbond Гуру

Securbond Гуру

Securbond Гуру

Securbond Гуру

vasgen Нуб

Securbond Гуру

Быстрый поиск

Ardino+W5100->Mqtt->OpenHab

Securbond Гуру

Securbond Гуру

Securbond Гуру

Securbond Гуру

Securbond Гуру

Securbond Гуру

vasgen Нуб

Securbond Гуру
