Часы на esp8266 и max7219 + android управление

fixed deletе MQTT file
add temperature parameter (+/-)
add second fonts combi clocks (4x6, 5x6)
add control static date > string



Возможно, имея блютуз, полезной функцией будет подключение датчиков типа LYWSD03MMC и аналогичных



Hi Ivan,

Hope you and your family are safe and doing fine.

I'm using "CLOCK_ESP8266-main.zip" clock firmwares and observed the below. Can you kindly check.

1) How to change the weather text to English? few texts are in Ukraine (apart from the city name mentioned in "The name of the place, you can see:" Note that I'm using openweathermap.

2) What is the option to change the web pages to English.

3) How do I display the BME280 weather data on the display.

4) Do you have plan to Implement 12HOUR format Date and Time.

Thanks in advance.



Понимаю, что где то среди 350 страниц возможно и есть ответ, но навскидку почему после выключения питания настройки периодически слетают в 0? Питание менял, перепрошивал, стирал ESPшку (NodeMCU V3) полностью. Так же первый раз подключается к Wi-Fi, пишет ОК, сохранено и в итоге не сохраняет, только с надцатой попытки. Версия 5.0.1....Вот единственное не помню, стоит ли резистор 10К, нужно разобрать глянуть, он может быть причиной такого поведения?



FillSU
Дело скорее в файловой системе SPIFFS, которая очень медленная
Замените в скетче на LittleFS или прошейте новую версию с этой файловой системой
Плюс наличие ОТА тормозит сильно работу часов, лучше удалить



Hi Ivan,

Hope you and your family are safe and doing fine.

I'm using latest "CLOCK_ESP8266-main.zip" (https://github.com/IZ76/CLOCK_ESP8266) clock firmwares and observed that the "Altitude" information is not getting displayed on the display. Find attached screen shot for your reference.

The observations mentioned earlier got resolved with google translate.

Thanks in advance.



Dave Beckham, metric "A" is short for "Ampere", the current flowing through the load.
The project does not provide for showing “Altitude” on the display.
This parameter is software based and very inaccurate. A GPS module is required for this.



Good afternoon.
Unfortunately, the BME-280 library used is not able to obtain altitude data

Код (C++):

#include <Adafruit_BME280.h>

Adafruit_BME280 bme; // use I2C interface
Adafruit_Sensor *bme_temp = bme.getTemperatureSensor();
Adafruit_Sensor *bme_pressure = bme.getPressureSensor();
Adafruit_Sensor *bme_humidity = bme.getHumiditySensor();

Absolutely right.
A - amperes
V – volts.
You can obtain this data from the corresponding sensors through the MQTT broker and display it on the screen.



Thanks Ivan for the clarification. Can you kindly let me know what are" tD, tU, tL, C " and Приблизна висота: 2858.59 m (from serial port)

Thanks again.



Many thanks for the quick reply.



I use:
tD - to display the temperature in the house
tU - outside temperature
tL - any other
C - an integer can be any indicator, for example the number of likes on YouTube or the number of door openings - data can be obtained via MQTT

Approximate height: 2858.59 m is the unit of calculation.
Library BMP-180/280 - knows how to calculate it.

Код (C++):

 float readTemperature();
  float readPressure(void);
  float readAltitude(float seaLevelhPa = 1013.25);
  float seaLevelForAltitude(float altitude, float atmospheric);
  float waterBoilingPoint(float pressure);

But in this project, I thought it was enough to output this data only to the com port. They practically do not change)))



Great Ivan. - You have incorporated lot of features. Keep up the good work.

Many thanks.



Доброго дня Всем!
Помогите разобраться - часики долгое время работали без проблем, этим летом началась какая-то дичь, глюки с отображением инфы на экране, самопроизвольные перезагрузки и в итоге сами по себе сбрасываются в какой то момент

Спойлер: Лог

14:54:41.443 ->
14:54:41.443 -> ets Jan 8 2013,rst cause:2, boot mode3,6)
14:54:41.484 ->
14:54:41.484 -> load 0x4010f000, len 3584, room 16
14:54:41.484 -> tail 0
14:54:41.484 -> chksum 0xb0
14:54:41.484 -> csum 0xb0
14:54:41.484 -> v2843a5ac
14:54:41.484 -> ~ld
14:54:41.527 ->
14:54:42.110 -> 00:30:45 LOAD /ssids.json(39): {"num":1,"nets":["banan18","qwsaz123"]}
14:54:42.145 -> 00:30:45 LOAD /jssids.json(22): {"banan18":"qwsaz123"}
14:54:42.191 -> 00:30:45 LOAD /wifis.json(93): {"APSSID":"ESP-Info","APPASS":"11112222","AUTH":"1234asdf5678","AUTHON":0,"HIDDENNETWORKS":0}
14:54:42.191 -> 00:30:45 LOAD /times.json(1078): {"ntpServerName":"time.nist.gov","timeZone":3,"isDayLightSaving":false,"rtcStat":false,"al_0_0":12,"al_0_1":30,"al_0_2":0,"al_1_0":7,"al_1_1":15,"al_1_2":0,"al_2_0":22,"al_2_1":55,"al_2_2":0,"al_3_0":0,"al_3_1":30,"al_3_2":0,"al_4_0":0,"al_4_1":0,"al_4_2":0,"md_0_0":1,"md_0_1":1,"md_1_0":2,"md_1_1":1,"md_2_0":6,"md_2_1":1,"md_3_0":7,"md_3_1":1,"md_4_0":13,"md_4_1":1,"md_5_0":19,"md_5_1":1,"md_6_0":8,"md_6_1":3,"md_7_0":1,"md_7_1":5,"md_8_0":1,"md_8_1":9,"md_0_2":"Новый Год!!!","md_1_2":"ПослеНовыйГод(((","md_2_2":"Ночь перед Рождеством","md_3_2":"Рождество","md_4_2":"Старый Новый Год!","md_5_2":"Крещение","md_6_2":"День цветов","md_7_2":"День шашлыка)))","md_8_2":"Отведи ребенка в школу","nc_hour_0":22,"nc_hour_1":24,"nc_hour_2":24,"nc_hour_3":24,"nc_hour_4":24,"nc_min_0":55,"nc_min_1":60,"nc_min_2":60,"nc_min_3":60,"nc_min_4":60,"nc_mess_0":"IvanZah","nc_mess_1":"","nc_mess_2":"","nc_mess_3":"","nc_mess_4":"","memory_hour_start":9,"memory_hour_end":23}
14:54:42.274 -> 00:30:45 LOAD /weaths.json(377): {"weathOn":1,"weatherHost":"0","weatherKey0":"271c426be565485ea483a5b65b173a81","weatherKey1":"","cityID0":"Щербинка","cityID1":"703845","personalCityName":"Щербинка","displayCityName":1,"displayForecastNow":1,"displayForecastToday":1,"displayForecastTomorrow":1,"displayForecastWind":"1","animNotWeather":1,"timeStartViewWeather":"7","timeEndViewWeather":"23"}
14:54:42.355 -> 00:30:45 LOAD /leds.json(949): {"NUM_VER_X":"1","NUM_MAX0":"4","NUM_MAX1":"4","rotate0":"90","rotate1":"90","mirror0":0,"mirror1":0,"timeDay":"7","timeNight":"21","volBrightsMax":"13","volBrightsMin":"1","typeSwitchBrightness":"0","fontCLOCK":"1","fontSizeData":"1","textDown":"0","dataDown":"1","displayData":"2","clockAndSec":"1","maxModeSec":"2","animPoint":"4","secLine":"1","timeScrollSpeed":"40","function00":"0","function01":"1","function02":"3","function03":"4","function04":"5","function05":"6","function06":"7","function07":"8","function08":"9","function09":"10","function10":"0","function11":"2","period00":"40","period01":"10","period02":"10","period03":"10","period04":"2","period05":"2","period06":"2","period07":"2","period08":"2","period09":"2","period10":"50","period11":"10","view00":"3","view01":"0","view02":"0","view03":"0","view04":"3","view05":"3","view06":"3","view07":"3","view08":"3","view09":"3","view10":"3","view11":"0","dataAlig":"2","clockAlig":"1"}
14:54:42.429 -> 00:30:45 LOAD /senss.json(499): {"mqttOn":0,"thingOn":0,"nmonOn":0,"sgpOn":0,"buzzerSet":"0","kuOn":"7","kuOff":"23","butStat":"0","messLang":"ru","params0":"0","params1":"10","params2":"0","params3":"0","params4":"0","params5":"0","params6":"0","params7":"0","sensors0":"0","sensors1":"0","sensors2":"0","sensors3":"0","sensors4":"0","sensors5":"0","sensors6":"0","sensors7":"0","corr0":"0","corr1":"0","corr2":"0","corr3":"0","corr4":"0","corr5":"0","corr6":"0","corr7":"0","pressSys":"1","updateOTA":0,"printCom":1,"beepSave":1}
14:54:42.476 -> 00:30:45 LOAD /mqtts.json(604): {"mqtt_server":"m13.cloudmqtt.com","mqtt_port":13011,"mqtt_user":"","mqtt_pass":"","mqtt_name":"ESP-Informer","mqtt_sub0":"Ulica/temp","mqtt_sub1":"Ulica/hum","mqtt_sub2":"Ulica/press","mqtt_sub3":"","mqtt_sub4":"","mqtt_sub5":"","mqtt_sub6":"","mqtt_sub7":"","mqtt_sub_inform":"Inform/mess","mqtt_pub_sensors0":"Informer/temp","mqtt_pub_sensors1":"Informer/tempUl","mqtt_pub_sensors2":"Informer/tempH","mqtt_pub_sensors3":"Informer/hum","mqtt_pub_sensors4":"Informer/press","mqtt_pub_sensors5":"Informer/alt","mqtt_pub_sensors6":"Informer/eco2","mqtt_pub_sensors7":"Informer/tvoc","timeOutMqtt":1200000}
14:54:42.564 -> 00:30:45 LOAD /things.json(327): {"channelIdWrite":"","writeApiKey":"","wrApiKey":"","writeFild0":0,"writeFild1":0,"writeFild2":0,"writeFild3":0,"writeFild4":0,"writeFild5":0,"writeFild6":0,"writeFild7":0,"channelIdRead":"","readApiKey":"","statThing0":0,"statThing1":0,"statThing2":0,"statThing3":0,"statThing4":0,"statThing5":0,"statThing6":0,"statThing7":0}
14:54:42.564 -> 00:30:45 LOAD /nmons.json(335): {"uuid":"","api_key":"","sensors_ID0":0,"sensors_ID1":3300,"sensors_ID2":0,"sensors_ID3":0,"sensors_ID4":0,"sensors_ID5":0,"sensors_ID6":0,"sensors_ID7":0,"latNmon":"","lonNmon":"","periodNmon":5,"writeNmon0":0,"writeNmon1":0,"writeNmon2":0,"writeNmon3":0,"writeNmon4":0,"writeNmon5":0,"writeNmon6":0,"writeNmon7":0,"nameNmon":"_Info"}
14:54:42.607 -> 00:30:45 LOAD /sgps.json(211): {"sgpCo2LivelAlarm":2,"eCo2AlarmEsp":true,"eCo2AlarmMqtt":false,"eCo2Led":true,"sgpTvocLivelAlarm":2,"tvocAlarmEsp":true,"tvocAlarmMqtt":false,"tvocLed":true,"setSgpCorr":0,"sgpCorrTemp":22.1,"sgpCorrHumi":45.2}
14:54:42.644 -> 00:30:45 LOAD /irs.json(115): {"ir_key0":33431775,"ir_key1":33444015,"ir_key2":33464415,"ir_key3":33448095,"ir_key4":33464410,"ir_key5":33448090}
14:54:43.708 -> 00:30:45 SAVE /times.json={"ntpServerName":"time.nist.gov","timeZone":3,"isDayLightSaving":false,"rtcStat":false,"al_0_0":12,"al_0_1":30,"al_0_2":0,"al_1_0":7,"al_1_1":15,"al_1_2":0,"al_2_0":22,"al_2_1":55,"al_2_2":0,"al_3_0":0,"al_3_1":30,"al_3_2":0,"al_4_0":0,"al_4_1":0,"al_4_2":0,"md_0_0":1,"md_0_1":1,"md_1_0":2,"md_1_1":1,"md_2_0":6,"md_2_1":1,"md_3_0":7,"md_3_1":1,"md_4_0":13,"md_4_1":1,"md_5_0":19,"md_5_1":1,"md_6_0":8,"md_6_1":3,"md_7_0":1,"md_7_1":5,"md_8_0":1,"md_8_1":9,"md_0_2":"Новый Год!!!","md_1_2":"ПослеНовыйГод(((","md_2_2":"Ночь перед Рождеством","md_3_2":"Рождество","md_4_2":"Старый Новый Год!","md_5_2":"Крещение","md_6_2":"День цветов","md_7_2":"День шашлыка)))","md_8_2":"Отведи ребенка в школу","nc_hour_0":22,"nc_hour_1":24,"nc_hour_2":24,"nc_hour_3":24,"nc_hour_4":24,"nc_min_0":55,"nc_min_1":60,"nc_min_2":60,"nc_min_3":60,"nc_min_4":60,"nc_mess_0":"IvanZah","nc_mess_1":"","nc_mess_2":"","nc_mess_3":"","nc_mess_4":"","memory_hour_start":9,"memory_hour_end":23}
14:54:43.785 -> RTC module off!
14:54:43.785 -> size time.file=66
14:54:43.827 -> 14:51:03 Load Stime(config): {"hour":14,"minute":51,"second":3,"year":2023,"month":12,"day":29}
14:54:43.827 -> 14:51:03 Connecting WiFi...
14:54:43.827 ->
14:54:43.827 ->
14:54:43.827 -> Huraaa!!! Connected to "banan18"(192.168.2.232)
14:54:43.827 ->
14:54:47.061 -> 14:51:06 Proba #1 14:54:47
14:54:48.656 -> Proba #2 14:54:47
..............
15:06:08.885 -> 15:06:07 fnCount= 1 period[fnCount]= 20 millis()= 687414 fnTimer= 707413
15:06:14.735 -> BUT MODE 1
15:06:14.735 -> 15:06:13 fnCount= 2 period[fnCount]= 10 millis()= 693263 fnTimer= 703262
15:06:14.735 -> 15:06:13 fnCount= 3 period[fnCount]= 10 millis()= 693264 fnTimer= 703264
15:06:14.735 -> 15:06:13 fnCount= 4 period[fnCount]= 2 millis()= 693272 fnTimer= 695268
15:06:14.781 -> 15:06:13 fnCount= 5 period[fnCount]= 2 millis()= 693280 fnTimer= 695276
15:06:14.781 -> 15:06:13 fnCount= 6 period[fnCount]= 2 millis()= 693288 fnTimer= 695288
15:06:14.781 -> 15:06:13 fnCount= 7 period[fnCount]= 2 millis()= 693297 fnTimer= 695292
15:06:14.781 -> 15:06:13 fnCount= 8 period[fnCount]= 2 millis()= 693305 fnTimer= 695301
15:06:14.781 -> 15:06:13 fnCount= 9 period[fnCount]= 2 millis()= 693313 fnTimer= 695309
15:06:14.827 -> 15:06:13 fnCount= 10 period[fnCount]= 50 millis()= 693321 fnTimer= 743317
15:06:14.827 -> 15:06:13 fnCount= 11 period[fnCount]= 10 millis()= 693329 fnTimer= 703325
15:06:16.962 -> BUT MODE 1
15:06:16.962 -> 15:06:15 fnCount= 0 period[fnCount]= 20 millis()= 695481 fnTimer= 715480
15:06:17.256 -> BUT MODE 2
15:06:19.381 -> BUT MODE 1
15:06:19.517 -> BUT MODE 2
15:06:20.751 -> BUT MODE 1
15:06:20.795 -> BUT MODE 2
15:06:21.096 -> BUT MODE 2
15:06:21.190 -> BUT MODE 2
15:06:22.486 -> BUT MODE 1
15:06:22.576 -> BUT MODE 2
15:06:23.416 -> BUT MODE 2
15:06:23.461 -> BUT MODE 2
15:06:24.311 -> BUT MODE 2
15:06:24.311 -> BUT MODE 2
15:06:25.974 -> BUT MODE 1
15:06:26.142 -> BUT MODE 2
15:06:26.698 -> BUT MODE 2
15:06:26.698 -> BUT MODE 2
15:06:27.372 -> BUT MODE 2
15:06:27.416 -> BUT MODE 2
15:06:27.757 -> BUT MODE 2
15:06:27.792 -> BUT MODE 2
15:06:28.565 -> BUT MODE 2
15:06:29.386 -> BUT MODE 1
15:06:29.992 -> BUT MODE 2
15:06:30.747 -> BUT MODE 2
15:06:30.954 -> BUT MODE 2
15:06:32.094 -> BUT MODE 1
15:06:32.212 -> BUT MODE 2
15:06:33.297 -> BUT MODE 1
15:06:33.297 -> BUT MODE 2
15:06:34.817 -> BUT MODE 2
15:06:34.850 -> BUT MODE 2
15:06:35.277 -> BUT MODE 2
15:06:35.411 -> BUT MODE 2
15:06:36.086 -> BUT MODE 2
15:06:36.566 -> BUT MODE 2
15:06:37.640 -> BUT MODE 1
15:06:37.640 -> 15:06:36 fnCount= 1 period[fnCount]= 20 millis()= 716175 fnTimer= 736175



1. У вас порт кнопки "колбасит". Подключите резистор R2-10К если вы используете кнопку. Или перемычку вместо R2 если не используете кнопку. Смотрите схему из первого поста.
2. Не публикуйте в сообщения полный лог ком порта. Там ваши личные данные типа апи-кей погоды, логин и пароль вашей вайфай сети.



Кнопки нет, но резистодорас 10К от D0 на землю был всё это время и это работало.
Очень смутило при разборке проблемы, то что после перепрошивки, устройство "хочу - работаю, хочу - нет" Решил проблему следующим образом - разобрал феном модуль ESP, там внутри флешка PN25F32, снял её и в программатор - а она не стирается, не проходит проверка чистоты, при чтении в некоторых областях мусор... Поставил Winbond W25Q32FV, прошил, уже больше суток полёт нормальный



Заменил древнюю прошивку v4.1 на 5,0, 17.08.2023. Но часы больше не видят датчик DHT11/22. Он убран с прошивки??? или можно его как то вернуть. В старой версии был народный монитор, и когда в регистрацию написать любую хрень часы брали температуру на улице прямо из текущего прогноза и выводили сразу как температуру на улице, при выборе народного монитора очень было удобно.



Good Morning All and hope all are fine.

I'm with IZ76/CLOCK_ESP8266 (firmware_17.08.2023.bin and littlefs_17.08.2023.bin) firmware. These two firmwares are working fine in the Wemos D1 Mini with MicroUSB connector.

When I test with Wemos D1 Mini Version 4.0.0 (USB C type connector), upload was successful, display was fine. When I do some changes in GUI, Wemos is rebooting after some time and flash is getting erased. This behavior I have observed in all of the new version 4.0.0 Wemos D1 mini.( I've tried with two Wemos D1 Mini V4.0.0)

Kindly note that older version of Wemos D1 mini is working fine.

Find below logs for your reference.

14:41:32.037 -> ======== COB OF SENSORY DATA RETRIBUTION =======================
14:41:32.270 -> 14:41:33 Temperature at BME280 sensor: 24.91 *C, humidity: 44.26%, pressure: 910 hPa, Approximate altitude: 2919.00 m
14:41:32.270 -> 14:41:33 Sensor [0] (corrected) = 0.00
14:41:32.317 -> 14:41:33 Sensor [1] (corrected) = 0.00
14:41:32.317 -> ======== KINETS ================================== == ========
14:41:39.941 -> Button mode: 4
14:41:39.941 -> Settings will be reset in 5 seconds!!!!!
14:41:45.930 -> 14:41:46 ESP clearing configuration files
14:41:45.930 -> 14:41:46 Visible /wifis.json
14:41:45.930 -> 14:41:46 Visible /ssids.json
14:41:45.976 -> 14:41:47 Visible /times.json
14:41:45.976 -> 14:41:47 Visible /memdates.json
14:41:45.976 -> 14:41:47 Visible /weaths.json
14:41:45.976 -> 14:41:47 Visible /leds.json
14:41:46.023 -> 14:41:47 Visible /infoscreen.json
14:41:46.023 -> 14:41:47 Visible /senss.json
14:41:46.023 -> 14:41:47 Visible /mqtts.json
14:41:46.023 -> 14:41:47 Visible /things.json
14:41:46.069 -> 14:41:47 Visible /sgps.json
14:41:50.017 ->
14:41:50.017 -> ets Jan 8 2013,rst cause:2, boot mode 3.7)
14:41:50.017 ->
14:41:50.017 -> load 0x4010f000, len 3460, room 16
14:41:50.017 -> tail 4
14:41:50.017 -> chksum 0xcc
14:41:50.017 -> load 0x3fff20b8, len 40, room 4
14:41:50.017 -> tail 4
14:41:50.017 -> chksum 0xc9
14:41:50.017 -> csum 0xc9
14:41:50.017 -> v00084a10
14:41:50.017 -> ~ld
14:41:50.906 -> 00:30:45 Saving WiFi data {"num":1,"nets":["IvanZah","IZ_Clock"]}
14:41:50.952 -> 00:30:45 Saving WiFi streaming {"IvanZah":"IZ_Clock"}
14:41:52.606 -> 00:30:45 Recording data from AR and zakhistu: {"APSSID":"ESP-Info","APPASS":"11112222","AUTH":"1234asdf5678","AUTHON": true,"HIDDENNETWORKS":false}
14:41:52.699 -> 00:30:45 Record hour data: {"ntpServerName":"ua.pool.ntp.org","timeZone":2,"isDayLightSaving":true,"al00":12," al01":30,"al02":0,"al10":7,"al11":15,"al12":0,"al20":22,"al21":55,"al22":0,"al30" :0,"al31":30,"al32":0,"al40":0,"al41":0,"al42":0,"ncH0":22,"ncH1":0,"ncH2":0 ,"ncH3":0,"ncH4":0,"ncM0":55,"ncM1":0,"ncM2":0,"ncM3":0,"ncM4":0,"ncMe0":"IvanZah" ,"ncMe1":"","ncMe2":"","ncMe3":"","ncMe4":""}
14:41:52.838 -> 00:30:45 Recording memory date data:

Kindly help on the above problem.

Thanks in advance.



Wemos thinks the button is pressed
Did you install a pull-up resistor on the button pin?



Thanks for the quick reply and suggestion. I've tried connecting 4.7K and 10K resistor between RST pin and 3.3volt. - It didn't worked.

Am I doing anything wrong here?.

Many thanks again.



обновка. функциональных изменений не много, но они есть
появились - возможность выбора случайного голоса озвучивания времени, тестовый режим для народного мониторинга и исправление нескольких мелких багов тоже присутствует.
главное отличие от предыдущей версии это изменение стилистики, оптимизация Джавы и ХТМЛ
обновленная аутентификация с использованием куков, писалась для другого устройства на ESP32, но и здесь не плохо прижилась
для удаления куков и разлогина необходимо жмакать по кнопке "Выход" в шапке (появляется при включенной и успешной аутентификации. пример на втором скрине)
хедеры, шапки, менюшки и таблицы теперь динамические, что позволило сократить код избавиться от однотипных бесконечных портянок как в JS так и в HTML, появилась возможность быстро и без проблем масштабировать таблицы
желающие могут тестировать.
